DC Powered BLE PIR Occ Control (Silvair) (06295)



The Silvair 06295 Series consists of DC-powered lighting controls with integrated PIR motion detection. The sensor detects movement through infrared and provides a 360° coverage pattern for indoor lighting-control applications.

Each model operates from 10–14V and includes a built-in node with an integrated 0–10V output. The single-channel design provides one dimmable output for compatible lighting systems.

Bluetooth Mesh creates a wireless dimmable network with communication distances up to 100 feet. Lighting can be operated through the Silvair Bluetooth app, while high-end trim, bi-level dimming, and scheduling are shown as supported functions.

Daylight harvesting provides automatic light adjustment according to ambient conditions. The series is available with a 2.5mm connection under part number 06295 and a 3.5mm connection under part number 06295 01.

Sale Off
DC Powered BLE PIR Occ Control w DH White 12ft for ASR Fixtures (Silvair) (06295)
DC Powered BLE PIR Occ Control w DH White 12ft for ASR Fixtures (Silvair) (06295)
DC Powered BLE PIR Occ Control w DH White 12ft for ASR Fixtures (Silvair) (06295)
DC Powered BLE PIR Occ Control w DH White 12ft for ASR Fixtures (Silvair) (06295)

Specs Sheet

IES Files & LM Reports

Instructions

How To Buy

PIR Motion Detection


Infrared motion detection provides a 360° coverage pattern.



Daylight Harvesting


Automatically adjusts connected lighting according to ambient light conditions.

Two Connection Options


Available with 2.5mm and 3.5mm connection configurations.

Features & Benefits

  • Bluetooth Mesh provides a wireless dimmable lighting-control network.
  • PIR sensing detects motion through infrared.
  • Daylight harvesting provides automatic light adjustment.
  • A 360° coverage pattern supports detection around the sensor.
  • Wireless communication operates at distances up to 100 feet.
  • Lighting can be operated through the Silvair Bluetooth app.
  • The built-in node includes an integrated 0–10V output.
  • Single-channel operation provides one output-control channel.
  • High-end trim, bi-level dimming, and scheduling are supported.
  • Two models provide 2.5mm and 3.5mm connection options.

Construction

  • Compact rectangular PIR control design
  • Integrated PIR motion sensor
  • Integrated built-in control node
  • Available with 2.5mm or 3.5mm connection options

Electrical

  • Input Voltage: 10–14V
  • Control Output: Integrated 0–10V output
  • Channels: One output-control channel
  • Communication Protocol: Bluetooth Mesh
  • Maximum Communication Distance: 100 ft
  • Operating Temperature: −4°F to 140°F
  • IP Rating: IP20

Optics

  • PIR infrared motion detection
  • Daylight harvesting with automatic light adjustment
  • 360° coverage pattern
  • 8 ft installation height
  • Maximum detection range: 17 ft

Mounting

    • Designed for indoor lighting-control applications
    • Published Mounting Height: Up to 12 ft
    • Installation heights from 8–13 ft
    • Two connection variants are available:
    • 06295: 2.5mm
    • 06295 01: 3.5mm

    • Controls

    • Silvair Bluetooth app operation
    • Bluetooth Mesh wireless control
    • PIR occupancy sensing
    • Daylight harvesting
    • High-end trim
    • Bi-level dimming
    • Scheduling
    • Single-channel 0–10V control

    Operations

    • More than 70,000 hours

    Warranty

    • 5-Year Product Warranty
